Olivetti d-Color MF2001 - Page 27

2KZ/2K0
1-2-3
l
Figure 1-2-2
*1 Excluding 230V AC model
Place the machine on a level surface.
1
22
24
2
3
4
5
24
6
7
8
9
10
11
12
22
22
22
21
13
14
15
18
19
20
16
17
23
25
26
27
28
Unpacking
1. Bottom case
2. Bottom pad R
3. Bottom pad L
4. Machine cover
5. Machine
6. Inner case R
7. Inner case L
8. Spacer A
9. Plastic bag (540 × 950)
10. Outer case
11. Upper pad R
12. Upper pad L
13. Toner container /YCM
14. Toner container /K
15. Plastic bag (250 × 650)
16. CD-ROM *
1
17. Installation guide, etc.
18. Plastic bag
19. Job separator tray
20. Plastic bag (400 × 600)
21. Power cord
22. Hinge joints
23. Quick installation guide
24. Reinforcement parts
25. Plastic bag
26. Lower pad
27. Front pad
28. Desiccant
