2KZ/2K0
2-3-3
YC104
1 VDN(K) O LVDS Video data signal (-)
Connected to
LSU connect
PWB
2 VDP(K) O LVDS Video data signal (+)
3 SH(K) O 0/3.3 V DC Sample/hold signal
4 BD(K) I 0/3.3 V DC(pulse) Horizontal synchronizing signal
5 SGND - - Ground
6 VDN(M) O LVDS Video data signal (-)
7 VDP(M) O LVDS Video data signal (+)
8 SH(M) O 0/3.3 V DC Sample/hold signal
9 BD(M) I 0/3.3 V DC(pulse) Horizontal synchronizing signal
10 SGND - - Ground
11 VDN(C) O LVDS Video data signal (-)
12 VDP(C) O LVDS Video data signal (+)
13 SH(C) O 0/3.3 V DC Sample/hold signal
14 BD(C) I 0/3.3 V DC(pulse) Horizontal synchronizing signal
15 SGND - - Ground
YC105
1 SLEEPOFF I 0/3.3 V DC Sleep Off signal
Connected to
engine PWB
2 ENG_HLD O 0/3.3 V DC Engine hold signal
3 SCAN_HLD O 0/3.3 V DC Scan hold signal
4 LIGHTSLEEP
N
O 0/3.3 V DC Light sleep shift signal
5 24V4 I 24 V DC 24 V DC power input from EPWB
6 24V4 I 24 V DC 24 V DC power input from EPWB
7 5V4 I 5 V DC 5 V DC power input from EPWB
8 3.3V0 I 3.3 V DC 3.3 V DC power input from EPWB
9 3.3V4 I 3.3 V DC 3.3 V DC power input from EPWB
10 3.3V4 I 3.3 V DC 3.3 V DC power input from EPWB
11 24VDOWN I 0/3.3 V DC 24 V down signal
12 GND - - Ground
13 GND - - Ground
14 GND - - Ground
15 GND - - Ground
16 GND - - Ground
17 HYP_SCL I 0/3.3 V DC(pulse) Clock signal
18 HYP_SDA I 0/3.3 V DC(pulse) Data signal
19 HYP_INT O 0/3.3 V DC Interrupt sijgnal
20 AQUA_CLK I 0/3.3 V DC(pulse) Clock signal
21 AQUA_SO O 0/3.3 V DC(pulse) Serial communication data signal output
22 AQUA_SI I 0/3.3 V DC(pulse) Serial communication data signal intput
Connector Pin Signal I/O Voltage Description
Y113010-4 Sevice Manual
