Olivetti d-Color MF2001 User Manual

2KZ/2K0
2-3-6
YC118
1 AUTODOWN O 0/3.3 V DC Auto down signal
Connected to
power source
PWB sub
2 GND - - Ground
3 5V0 I 5 V DC 5 V DC power input from PSPWB-S
YC41
1 +24V1 O 24 V DC 24 V DC power output to CONFM
Connected to
controller fan
motor
2CONTFANDR
N
O 0/24 V DC CONFM: On/Off
3 N.C. - - Not used
Connector Pin Signal I/O Voltage Description
Service Manual Y113010-4
