2KZ/2K0
2-3-19
YC26
27 GND - - GROUND
Connected to
main PWB
28 24VDOWN I 24 V DC 24 V DC down signal
29 3.3V4 O 0/3.3 V DC 3.3 V DC power output to MPWB
30 3.3V4 O 0/3.3 V DC 3.3 V DC power output to MPWB
31 3.3V0 O 0/3.3 V DC 3.3 V DC power output to MPWB
32 5V4 O 5 V DC 5 V DC power output to MPWB
33 24V4 O 24 V DC 24 V DC power output to MPWB
34 24V4 O 24 V DC 24 V DC power output to MPWB
35 LIGHT_SLEE
PN
I 0/3.3 V DC Light sleep shift signal
36 SCAN_HLD I 0/3.3 V DC Scan hold signal
37 ENG_HLD I 0/3.3 V DC Engine hold signal
38 SLEEPOFF O 0/3.3 V DC Sleep return signal
YC28
1 FUSER_FAN_
REM
O 0/24 V DC FUFM1: On/Off
Connected to
fuser fan
motor
2 GND - - GROUND
3 FUSER_FAN_
REM
O 0/24 V DC FUFM2: On/Off
4 GND - - GROUND
YC29
1 GND - - GROUND
Connected to
temperature
sensor
2 TMPDATA I Analog TEMS detection voltage (Temperature)
3 WETCLK0 O 0/3.3 V DC (pulse) TEMS clock signal
4 WETCLK1 O 0/3.3 V DC (pulse) TEMS clock signal
5 HUMDATA I Analog TEMS detection voltage (Humidity)
Connector Pin Signal I/O Voltage Description
Y113010-4 Sevice Manual
