2KZ/2K0
2-3-22
YC7
1 +5V2 O 5 V DC 5 V DC power output to MPWB
Connected to
main PWB
2 +5V2 O 5 V DC 5 V DC power output to MPWB
3 +5V2 O 5 V DC 5 V DC power output to MPWB
4 +5V2 O 5 V DC 5 V DC power output to MPWB
5 +5V2 O 5 V DC 5 V DC power output to MPWB
6 +5V2 O 5 V DC 5 V DC power output to MPWB
7 +5V2 O 5 V DC 5 V DC power output to MPWB
8 GND - - GROUND
9 GND - - GROUND
10 GND - - GROUND
11 GND - - GROUND
12 GND - - GROUND
13 GND - - GROUND
14 GND - - GROUND
15 SLEEP1 I 0/3.3 V DC Sleep 1 control signal: On/Off
YC8
1 +24V2 O 24 V DC 24 V DC power output to ECPWB
Connected to
engine PWB,
engine con-
nect PWB
2 +24V2 O 24 V DC 24 V DC power output to ECPWB
3 GND - - GROUND
4 GND - - GROUND
5 GND - - GROUND
6 GND - - GROUND
7 GND - - GROUND
8 +24V2 O 24 V DC 24 V DC power output to EPWB
9 +24V2 O 24 V DC 24 V DC power output to EPWB
10 +24V2 O 24 V DC 24 V DC power output to EPWB
YC9
1 NC - - Not used
Connected to
engine con-
nect PWB
2 SLEEP2 I 0/3.3 V DC Sleep 2 control signal: On/Off
Connector Pin Signal I/O Voltage Description
Service Manual Y113010-4
