2KZ/2K0
2-3-25
YC9
1 IH_OUT1 O 390 V DC Resonance circuit output
Connected to
IH coil
YC10
1 IH_OUT2 O 1000 V DC Resonance circuit output
Connected to
IH coil
CAUTION: Connectors YC1, YC3, YC6, YC9 and YC10 are not grounded, therefore, use caution not to
damage the connectors during measurement of voltages.
Connector Pin Signal I/O Voltage Description
Y113010-4 Sevice Manual
