2KZ/2K0
1-3-22
U034
5. Change the setting value using the cursor left/right keys or numeric keys.
For output example 1, increase the value. For output example 2, decrease the value.
Figure 1-3-2
6. Press the start key. The value is set.
Remark
Changing the larger sizes settings affects those for the smaller sizes.
Caution
Check the copy image after the adjustment. If the image is still incorrect, perform the following
adjustments in maintenance mode.
Adjustment: Center line adjustment
1. Press the system menu key.
2. Press the start key to output a test pattern.
3. Press the system menu key.
4. Select the item to be adjusted.
Item No. Description
Correct image
Output
example 1
Output
example 2
Leading edge
registration
(20 ± 1.5 mm)
U034
U066
( P.1-3-31)
U071
( P.1-3-36)
Display Description
Setting
range
Initial
setting
Change in
value per step
MPT Paper feed from MP tray -128 to 127 0 0.1 mm
Cassette1 Paper feed from cassette 1 -128 to 127 0 0.1 mm
Cassette2 Paper feed from optional
cassette 2
-128 to 127 0 0.1 mm
Cassette3 Paper feed from optional
cassette 3
-128 to 127 0 0.1 mm
Duplex Duplex mode (second) -128 to 127 0 0.1 mm
Service Manual Y113010-4
To Next Page
