2. Optionally, enter the advanced settings in the Advanced settings area.
3. In the Assessment area, configure the assessment.
► Click Edit configuration or click in the table to open the Assessment configuration dialog box,
and then edit the assessment limits.
► Select the Automatic assessment check box to enable the automatic assessment.
Note: For the assessment limit definitions, see 15.3 "Assessment limits" on page 107.
4. By using the Open breaker, Close breaker and Supply motor buttons in the Measurements area
of Primary Test Manager (see 11.1 "Test control commands" on page 85) you can check whether all
cables are correctly connected and bring the circuit breaker to the proper state. For testing the
minimum pickup by the open sequence the circuit breaker must be closed and vice versa.
Supply settings
1,2,3
Select the preconfigured motor supply setting from the asset data or select
Custom to enter custom settings.
Motor supply voltage Rated voltage of the motor supply
Click AC or DC for AC or DC motor supply voltage respectively.
Test frequency Motor supply frequency (AC only)
Max. supply duration Maximum duration of supplying the motor if not stopped automatically
1. Only available in the guided test workflow
2. Data taken from the nameplate
3. Only available if CIBANO 500 is selected as source
Table 17-24: Advanced settings of the Minimum Pickup test
Setting Description
Supply during coil supply
Enable Select the Enable check box to supply voltage on the B3 socket during test
execution.
1
1. The B3 socket must be configured as Supply and the coil supply voltage must be specified.
Supply voltage Voltage supplied on the B3 socket (same as the coil supply voltage)
Supply before test Time interval within which the voltage is supplied before the test starts
Test sequence
Command impulse
duration
Duration of the command pulse of the automated test sequence
Pause between
impulses
Time interval between impulses of the automated test sequence
Table 17-23: Settings of the Minimum Pickup test (continued)
Setting Description
