CIBANO 500 PTM User Manual
242 OMICRON
Measurement
To perform a measurement:
1. In the Settings and conditions area, enter the settings of the Motor Current test.
2. Optionally, enter the advanced settings in the Advanced settings area.
Table 17-81: Settings of the Motor Current test
Setting Description
Motor supply
Supply source Click CIBANO 500 to supply the motor with CIBANO 500.
Click External source to supply the motor externally.
Supply settings
1,2
1. Only available in the guided test workflow and if CIBANO 500 is selected as source
2. Data taken from the nameplate
Select the preconfigured motor supply setting from the asset data or select
Custom to enter custom settings.
Motor supply voltage Rated voltage of the motor supply
Click AC or DC for AC or DC motor supply voltage respectively.
Test frequency Motor supply frequency (AC only)
Max. supply duration Maximum duration of supplying the motor if not stopped automatically
Coil supply
Supply source Click CIBANO 500 to supply the coils with CIBANO 500.
Click External source to supply the coils externally.
Supply settings
1,2
Select a preconfigured coil supply setting from the asset data or select
Custom to enter custom settings.
Coil supply voltage Rated voltage of the coil supply
Click AC or DC for AC or DC coil supply voltage respectively.
Test frequency Coil supply frequency (AC only)
Table 17-82: Advanced settings of the Motor Current test
Setting Description
Other
Sample rate Measurement sample rate
Charging current
Begin Start of the charging current evaluation in percent of the total charging
duration of the motor
End End of the charging current evaluation in percent of the total charging
duration of the motor
