Typical Ethernet network
interface card with BNC and
RJ-45 connectors
Typical PCMCIA Ethernet
network interface card for
notebooks with BNC and
RJ-45 connectors
Offline Not connected to CPC 100, for example, "offline test
preparation" means: preparing a test with a PC using
CPC Explorer and CPC Editor.
PC Card
PCMCIA network interface card. See also
⇒ NIC...
Press The term "press" in the context of working with the CPC 100
software (for example, press the I
NSERT C ARD key) means:
a) pressing a menu or an accelerator key
b) or setting the focus (
⇒ Glossary) onto a UI (⇒ Glossary)
element by navigating to it with the handwheel, and
pressing the handwheel to execute the E
NTER function
Quantity The term "quantity" designates a physical unit, such as Volt (V)
or Ampere (A).
rd rd = reading; used for determining the error value of a
measurement range (For an example, see ”General” on page
16-2.)
sel sel = frequency-selective measurement (see page 3-6)
Test object The object to be tested by CPC 100, for example, a current or
voltage transformer.
Trigger A trigger is an "initiator". In this case it is an electrical signal, for
example, at CPC 100 binary input, whose occurrence causes
direct follow-up actions, such as switching off the output signals.
User
interface (UI)
Operational surface of a software. A user interface contains all
control elements necessary to work with the software.
V0 CPC 100 version V0 (see ”CPC 100 Versions” on page 15 of
this chapter)
V1 CPC 100 version V1 (see ”CPC 100 Versions” on page 15 of
this chapter)
