CT Excitation (Kneepoint)
Use the CTExcitation test card to record the excitation curve of a current
transformer. This test performs an automatic injection of a test voltage of up to
2kV to the current transformer’s secondary side.
Figure 9:
Setup for recording a
CT excitation curve
