CPC 100 V1.41
16 - 8
2kV AC output
While using the 2kV AC output, disconnect any cables that may be plugged in
to any of the high-current outputs (800A AC or 400A DC).
Table 4:
Technical data of
2kV AC output - all
ranges
Table 5:
Technical data of
2kV AC output at a
voltage range of 2000V

2kV AC output - all ranges
Connection High-voltage sockets
Insulation Insulated against all other inputs and outputs.
Voltage with reference to earth must not exceed
2000V
rms
and 2800V
peak
on either socket.
Reinforced insulation against mains power supply, all
interfaces and other safety low-voltage circuits.
Measurement Internal precision current and voltage measurement,
integrated in CPC 100 (for details, see tables below).
Abs. max. rating: limited through output
Connection: internally connected
2kV AC output at a voltage range of 2000V
Maximum current Peak current I
peak
< 3.0A
Effective current I
rms
< 1.25A
Output power at: typical apparent
power S
max
typical time t
max
frequency
2000V / 1.25A
2000V / 1A
2000V / 0.5A
2500VA
2000VA
1000VA
60s
130s
> 2hrs
50…200Hz
50...200Hz
50...400Hz
