CPC 100 V1.41
16 - 18
6A DC current output
While using the 6A DC output, disconnect any cables that may be plugged in to
any of the high-current outputs (800A AC or 400A DC), or to the 6A / 130V AC
output.
Table 12:
6A DC output technical
data
6A DC output
Connection 4mm banana sockets
Insulation The 6A DC output is internally connected with the
6A / 130V AC output. Apart from this, the output is
insulated against all other inputs and outputs.
Voltage with reference to earth must not exceed
200Vrms and 280V peak on either socket.
Reinforced insulation against mains power supply, all
interfaces and other safety low-voltage circuits.
Protection If a large inductance is connected, and the output is
switched off, an internal arc-suppression diode protects
the user from voltage spikes from the inductance.
Additionally, a surge arrester with a short circuit spring
that, in case of an overload, applies a short circuit to
the output and protects the user if the arc-suppression
should not be sufficient.
The existence of a discharge voltage potential is also
indicated by a lit LED - even if CPC 100 is switched off.
This LED is situated at the right-hand side of the
6A DC output sockets.
Current / voltage
measurement
No internal measurement provided. To measure this
output signal, connect it to a measuring input:
current measurement: at IAC/DC input
voltage measurement: at VDC input
Output power at: typical power
P
max
typical time t
max
6.0A
3.0A
360W
180W
> 2hrs
>> 2hrs
