Omicron CPC 100 Reference Manual

CPC 100 V1.41
16 - 22
10A IAC/DC Input
Table 15:
10A AC/DC input
technical data
Note: Do not connect the 2kV output to this input! The 2kV output is
measured internally.
10A IAC/DC input
Connection 4mm banana sockets
Measurement
ranges (autoranging)
0 ... 10A
0 ... 1A
Insulation Insulated against all other inputs and outputs.
Voltage with reference to earth must not exceed
270V
rms
and 380V
peak
on either input socket.
Reinforced insulation against mains power supply, all
interfaces and other safety low-voltage circuits.
Protection The 10A IAC/DC current input is fuse-protected (see
below). For measuring currents on high inductances,
the input is protected before the fuse.
This is done by an internal surge arrester with a short
circuit spring that, in case of an overload, applies a
short circuit to the output, and protects the user in case
the fuse is blown, and a current is still forced through
the input with a high voltage.
Maximum current 11A
rms
Accuracy
• AC operation
(autoranging)
10A: typ. error < ± 0.05% (rd) ± 0.05% (fs),
guaranteed < ± 0.1% (rd) ± 0.1% (fs)
1A: typ. error < ± 0.05% (rd) ± 0.05% (fs),
guaranteed < ± 0.1 % (rd) ± 0.1% (fs)
Possible crest factor: < 3.0
Phase tolerance at full scale:
10A: typ. error < ± 0.1°
guaranteed < ± 0.2°
1A: typ. error < ± 0.15°
guaranteed < ± 0.3°
