Technical Data
16 - 31
Connector for Extern
al Safety Functions
Figure 7:
Connector for external
safety functions - pin
assignment
The pins 1 and 2 provide an output of 12.9
V
/
85.5
mA (V1) and 5V
/
2.5 (V0).
Figure 8:
Connector for external
safety functions - wiring
scheme
1
warning light green (TTL level)
2
warning light red (TTL level)
3
start button (n/o)
4
common start n/o & em. stop
5
emergency stop
ground
6
ground
7
start button (n/c)
8
ground
9
1
9
external Start button (n/c)
external Emergency Stop button
warning
light
red
warning
light
green
external Start
button (n/o)
346
