Omicron CPC 100 Reference Manual

CPC 100 V1.41
10 - 2
Test Assessment
The test assessment is a manual procedure carried out by the user.
The example below shows an assessment made at a VTRatio test card.
However, the assessment procedure is carried out in the same fashion on all
test cards.
Figure 1:
Example:
VTRatio test card - test
assessment
After the test, set the focus on the assessment symbol by turning the handwheel.
If this symbol is selected, the test card’s bottom line shortly shows "Change test
assessment [OK/ Failed]", and then returns to "Assessed: n/a".
The scale symbol designates that no manual assessment was done yet.
The context-dependent menu keys now provide the option to manually assess
the test as either O K or F
AILED.
Assessing the test appends the actual date and time to the bottom line string
"Assessed:" and displays a corresponding icon on the screen:
Pressing C
LEAR ASSESS. clears both the assessment and the assessment’s
date/time stamp in the bottom line, and lets you renew your assessment.
Test OK
Test failed
