Omicron CPC 100 Reference Manual

CPC Editor
14 - 5
Appending a Test Card
Appending a test card means:
• appending it to an empty list, that is, make it the first test card
• appending it to the last position of an already existing list of test cards.
When CPC Explorer starts, the list view pane is empty. To insert a test card,
either
– right-click the list view pane to open the shortcut menu and click I
NSERT
T
EST CARD...
Figure 2:
Shortcut menu of the list
view pane
– or select the pull-down menu item I NSERT | TEST CARD...
In the Insert Test Card dialog box, select the test card of your choice and click
A
PPEND.
Figure 3:
Insert Test Card dialog
I NSERT only
becomes available
if there are already
test cards in the list
(refer to ”Inserting a
Test Card” on page
6 of this chapter).
