CPC 100 Inputs
BIN IN Binary Input
Table 14:
BIN IN binary input
technical data
Binary input BIN IN
Connection 4mm banana sockets
Insulation Insulated against all other inputs and outputs.
Voltage with reference to earth must not exceed
300V
rms
and 420V
peak
on either input socket.
Reinforced insulation against mains power supply, all
interfaces and other safety low-voltage circuits.
Sampling frequency 1kHz
Max. voltage 330V
rms
Resolution 1ms
Operation potential-free or external DC voltage operation
• ext. DC voltage
nominal voltage active: 100V DC (min. > 0V)
inactive: input open or voltage < -20V
• potential-free
R
on
< 10kΩ
R
off
> 1MΩ
Input resistance
> 100k
Ω
