Omicron CPC 100 Reference Manual

CPC 100 V1.41
16 - 32
Environmental Conditions
Climate
Table 19:
Environmental
conditions - climate
Shock and Vibration
Table 20:
Environmental
conditions - shock and
vibration
Climate
Operating temperature -10° ... +55°C (+14 ... +131F)
Storage and transportation -20° ... +70°C (-4 ... +158F)
Humidity 5 ... 95% relative humidity, no condensation
Drip-water protection IP22, tested according to EN 60529/A1:2000
(13.2, 13.3, 14.2.2), not operating, upright
position, that is, front panel must be
horizontal.
IP22 means drip-water protection. Never
operate CPC 100 with a wet front panel or
wet sockets.
Make sure no water can come in through the
ventilation slots.
Note: Since the AC and DC output sockets of CPC 100 can carry life-
hazardous voltage potential and provide life-hazardous currents, we
strongly advise you not to carry out tests with a wet CPC 100.
Before switching on CPC 100, make sure it is completely dry.
Shock and vibration
Vibration • Tested according to IEC68-2-6 (operating
mode)
• Frequency range 10 ... 150Hz
• Acceleration 2g continuous (20 m/s²);
10 cycles per axis
Shock • Tested according to IEC68-2-27 (operating
mode)
• 15g / 11ms, half-sinusoid, each axis
