CPC 100 V1.41
7 - 12
Measurements
IDC: actual test current from 6A DC output
VDC: voltage that IDC generates at the transformer’s secondary
winding, measured at V DC input
R meas: transformer’s winding resistance, calculated from VDC / IDC
Time: total elapsed test time
Dev: deviation in % between the maximum and the minimum
measured values evaluated within the last 10 seconds of the
measurement. The results are considered stable if Dev < 0.1%.
Press the context-dependent K
EEP RESULT menu key to
save the actual result in the measurement table. This adds a
new line to the measurement table and the next measurement
can be started.
