Omicron CPC 100 Reference Manual

CPC 100 V1.41
15 - 2
Working with Excel CPC 100 File Loader
Excel CPC 100 File Loader allows loading XML files generated with CPC 100
into Microsoft Excel templates for post processing. Every test card within an
XML file is represented by a sheet of a Microsoft Excel workbook. You can load
new XML files into the Microsoft Excel template by generating all sheets or by
loading data into existing sheets of the workbook. The mapping between the
data in the file and in the sheets is done by using the same name for the
CPC 100 test card and the corresponding sheet.
Note: Due to the mapping of the data, use unique name for the test cards in the
XML files.
Because the results are converted into Microsoft Excel compatible numbers,
post processing of the data is straightforward. In a blank customer sheet, you
can reference to the data in the sheets designed by OMICRON electronics using
Microsoft Excel formulas. Then, if the data in the OMICRON sheets is updated,
the customer sheet is updated, too. By this means, special forms for post
processing of the data, the so-called templates, can be created easily.
