Omicron CPC 100 Reference Manual

Technical Data
16 - 27
10V V DC Input
Table 18:
10V VDC input
technical data
10V VDC input
Connection 4mm banana sockets
Measurement
ranges (autoranging)
0 ... 10V
0 ... 1V
0 ... 100mV
0 ... 10mV
Insulation Insulated against all other inputs and outputs.
Voltage with reference to earth must not exceed
140V
rms
and 200V
peak
on either input socket.
Reinforced insulation against mains power supply, all
interfaces and other safety low-voltage circuits.
Maximum voltage 50V
rms
/ 75V
peak
Accuracy 10V: typ. error < ± 0.03% (rd) ± 0.08% (fs),
guaranteed < ± 0.05% (rd) ± 0.15% (fs)
1V: typ. error < ± 0.03% (rd) ± 0.08% (fs),
guaranteed < ± 0.05% (rd) ± 0.15% (fs)
100mV: typ. error < ± 0.05% (rd) ± 0.1% (fs),
guaranteed < ± 0.1% (rd) ± 0.2% (fs)
10mV: typ. error < ± 0.05% (rd) ± 0.15% (fs),
guaranteed < ± 0.1% (rd) ± 0.3% (fs)
Input resistance
500k
Ω
Resolution Measurement Display
10V: 400 μV/bit
1V: 75 μV/bit
100mV: 4 μV/bit
10mV: 0.4 μV/bit 0.1 μV
