CPC 100 V1.41
14 - 8
Renaming a Test Card
To rename the currently selected test card to any new name of your choice
– either right-click the list view pane to open the shortcut menu and click
R
ENAME
–or select TEST CARD | RENAME
Enter the name of our choice (256 characters max.) and press E NTER.
Saving a Test
Click the S AVE icon or select F ILE | SAVE with the "Save as type:" option
"CPC files (*.xml)" to save the currently open test, that is, the test card(s) listed
in the list view with all of their settings, under its actual name.
If this test does not have a name yet, the Save As dialog box opens. Browse to
the destination folder of your choice, and name your test accordingly.
Saving a Test as Template
Using the F ILE | SAVE AS . . . command with the "Save as type:" option "CPC
templates (*.xmt)", any test file can be saved as a test procedure template, that
is, a user-defined template containing one or more test cards with all of their
specific test settings but without test results.
To learn more about templates in general, please refer to ”Creating Defaults and
Templates” on page 2-42.
In this process, the settings of the original name.xml file are taken over to the
newly created test procedure template name.xmt. Possible test results in the
name.xml file, however, are not taken over. The original file name.xml remains
unchanged.
The template is then uploaded to CPC 100 using CPC Explorer.
Note: The file name extension .xml is appended automatically. Do not enter
any other file name extension as the F
ILE OPEN command will then
not show this file anymore.
Note: The file name extension .xmt is appended automatically. Do not enter
any other file name extension as CPC 100 will not recognize it as valid
template.
