Omicron CPC 100 Reference Manual

CPC 100 V1.41
16 - 28
CPC 100 Combined Specifications
Resistance Measurement
The accuracy of the combined measurements can be calculated from the
respective input and output specifications.
The tables below give some examples
4-wire measurement with 400A DC output and 10V VDC input
Current Resistance Voltage Typ. error Guaranteed
400A 10µ
Ω 4mV 0.70% 1.35%
400A 100µ
Ω 40mV 0.55% 1.10%
400A 1mΩ 400mV 0.50% 0.95%
400A 10m
Ω 4V 0.50% 0.95%
4-wire measurement with 6A DC output and 10V VDC input
Current Resistance Voltage Typ. error Guaranteed
6A 100m
Ω 0.6V 0.35% 0.60%
6A 1
Ω 6V 0.35% 0.60%
1A 10Ω 10V 0.25% 0.40%
2-wire measurement with 10V VDC input
Current Resistance Voltage Typ. error Guaranteed
< 5mA 100
Ω 0.60% 1.20%
< 5mA 1k
Ω 0.51% 1.02%
< 5mA 10k
Ω 0.50% 1.00%
