Omicron CPC 100 Reference Manual

CPC 100 V1.41
17 - 16
Clamps
Table 13:
Ordering information for
clamps
Plugs
Table 14:
Ordering information for
plugs
Power cord C19, 3 x 1.5mm², length 2.5m
• standard with open ends
1
• VII connector, for most of Europe and the
Middle East
• ZA connector for South Africa, Namibia and
parts of India
• British BS connector for UK, Hong Kong and
parts of India
Power cords for other countries on request.
Please contact OMICRON electronics.
VEHK0621
VEHK0616
VEHK0620
VEHK0624
1. If your CPC 100 has a power cord with open ends, connect the three cables as follows:
green/yellow PE (protective earth)
brown phase
blue N (neutral)
Ordering description for cables Article number
Ordering description for clamps Article number
High-voltage connection clamp to connect to
4mm banana plug, set of 2 black and 2 red
clamps
VEHZ0610
Crocodile clamp to connect to 4mm banana
plug, set of 2 black and 2 red clamps
VEHZ0620
Ordering description for plugs Article number
Plug for AC low voltage level input V2AC
(0 ... 3V), "Odu
®
MINI SNAP"
(refer to ”Assembly Instructions for Odu MINI-
SNAP Plug” below).
VEHS0610
Low voltage adapter,
4mm banana to Odu
®
MINI SNAP plug
VEHK0623
