Omicron CPC 100 Reference Manual

CPC 100 V1.41
2 - 28
Settings Page
Some test cards include the S ETTINGS menu key. Pressing the S ETTINGS
menu key opens the Settings page.
Figure 19:
Main page with
S
ETTINGS menu key
The Settings page with the exception of the TRRatio test card looks as shown
below.
Figure 20:
Settings page
The Settings page allows setting the test cards individually. At the
Device Setup tab in the Options view (see ”Options” on page 33 of this
chapter), the same properties can be set for all test cards of a test procedure.
As a rule, do not use the Settings page described here but the Device Setup
tab in the Options view to set the test cards. Making different settings for the
test cards is rarely a good idea. Set the test cards individually using the Settings
page only in well-founded cases.
If a test card contains results, the settings cannot be changed. When a file
containing results is loaded, the Settings page can be used to view the settings
of the test procedure.
