Omicron CPC 100 Reference Manual

Technical Data
16 - 7
400A DC output
While using the 400A DC output, disconnect any cables that may be plugged in
to the 800A AC output. These outputs are internally connected.
Table 3:
400A DC output
technical data

400A DC output
Connection 10mm connectors
Insulation Internally connected to the 800A AC output, insulated
against all other inputs and outputs.
Voltage with reference to earth must not exceed
300V
rms
and 420V
peak
on either socket.
Reinforced insulation against mains power supply, all
interfaces and other safety low-voltage circuits.
Output power at: typ. power P
max
typical time t
max
400A
300A
200A
100A
2600W
1950W
1300W
630W
140s
3min
> 2hrs
>> 2hrs
Measurement Internal precision current measurement from
0 ... 400A DC
Abs. max. rating: limited through output
Accuracy: typ. error < ± 0.2% (rd) ± 0.05% (fs),
guaranteed < ± 0.4% (rd) ± 0.1%(fs)
Resolution: Measurement Display
100 mA/bit 10 mA
Connection: internally connected
