Omicron CPC 100 Reference Manual

CPC 100 V1.41
14 - 6
Inserting a Test Card
Inserting a test card means: inserting it into an already defined list of test cards.
The procedure of inserting resembles the one of appending a test card
(described in ”Appending a Test Card” on page 5 of this chapter). The difference
is that the inserted test card is positioned in the list right before the currently
selected test card rather than appended to the end.
Figure 4:
Example: inserting a
VTRatio test card to an
existing list of test cards
Inserting from File
Select I NSERT | FROM FILE... to browse for a previously saved .xml file. This
.xml file is a test file that was either
• previously created with CPC Editor, and saved to the computer’s hard disk
• or previously created (and even executed and assessed) with CPC 100, and
then uploaded to the computer’s hard disk by means of CPC Explorer.
Just like inserting a single test card, inserting an .xml file means, positioning its
entire contents (one or more test cards) in the list right before the currently
selected test card.
Already defined list of test
cards, TRRatio selected.
Select
–I
NSERT |TEST C ARD
–VTRatio
–I
NSERT
VTRatio is inserted
before the selected
TRRatio test card.
