Output "Ext. Booster" (option)
The output "Ext. Booster" does not have own specifications. They are
determined by the device connected to this output, for example, by the current
booster CPCB2.
For more information about boosters, please refer to ”Accessories” in
chapter 17.
Fuse Type: 6.3A T
The 6.3 Amps slow-acting wire fuse 5x20mm, situated
at the front panel’s AC OUTPUT group, protects both
the AC OUTPUT in 3A and 6A current mode and the
DC OUTPUT
Note 1: If a test object with a large inductance is connected to CPC 100, earth
both ends of the test object before you disconnect it from CPC 100.
Note 2: Do not connect a large inductance to this output in any other test card
but RWinding (winding resistance) and TRTapCheck (tap changer
winding resistance and on-load tap changer interruption check).
Unlike other test cards, RWinding and TRTapCheck provide special
additional safety functions.
Note: The connector "Ext. Booster" is always galvanically connected to
mains, regardless whether or not an external booster is selected on
the software tab Options | Device Setup, the green warning light (0)
is on, the outputs are turned off or the Emergency Stop button is
pressed.
Handle with extreme caution!
6A DC output
