Omicron CPC 100 Reference Manual

Technical Data
16 - 9
Measurement
Voltage
Voltage and current
Range: 0 ... 2000V AC
Accuracy: typ. error <± 0.05%(rd) ± 0.05%(fs),
guaranteed <± 0.1% (rd) ± 0.1% (fs)
Possible crest factor: < 1.5
Phase tolerance
at full scale:
typ. error < ± 0.1°,
guaranteed < ± 0.2°
Resolution: Measurement Display
100 mV/bit 10 mV
Current Ranges
(automatic range
selection):
0 ... 5A AC
0 ... 500mA AC
0 ... 50mA AC
1
Accuracy: 5A: typ. error
< ± 0.2% (rd) ± 0.05% (fs),
guaranteed
< ± 0.4% (rd) ± 0.1% (fs)
500mA:typ. error
< ± 0.05% (rd) ± 0.05% (fs),
guaranteed
< ± 0.1% (rd) ± 0.1% (fs)
50mA
1
: typ. error
< ± 0.1% (rd) ± 0.1% (fs),
guaranteed
< ± 0.2% (rd) ± 0.2% (fs)
Possible peak value: ± 20A
Resolution: Measurement Display
5A: 1 mA/bit
500mA: 100 μA/bit
50mA
1
:
10 μA/bit 1 μA
Phase tolerance
at full scale:
typ. error < ± 0.1°,
guaranteed < ± 0.2°
1. Available for the CPC 100 serial number Dxxxxx and higher.
2kV AC output at a voltage range of 2000V
