Omicron CPC 100 Reference Manual

CPC 100 V1.41
6 - 6
Dy5 U/H1 V/H2 n/X0 u/X1
V/H2 W/H3 n/X0 v/X2
W/H3 U/H1 n/X0 w/X3
Yd5 U/H1 N/H0 w/X3 u/X1
V/H2 N/H0 u/X1 v/X2
W/H3 N/H0 v/X2 w/X3
Yz5 U/H1 V/H2 n/X0 u/X1
V/H2 W/H3 n/X0 v/X2
W/H3 U/H1 n/X0 w/X3
Dd6 U/H1 V/H2 v/X2 u/X1
V/H2 W/H3 w/X3 v/X2
W/H3 U/H1 u/X1 w/X3
Yy6 U/H1 V/H2 v/X2 u/X1
V/H2 W/H3 w/X3 v/X2
W/H3 U/H1 u/X1 w/X3
Dz6 U/H1 V/H2 v/X2 u/X1
V/H2 W/H3 w/X3 v/X2
W/H3 U/H1 u/X1 w/X3
Dy11 U/H1 V/H2 u/X1 n/X0
V/H2 W/H3 v/X2 n/X0
W/H3 U/H1 w/X3 n/X0
Yd11 U/H1 N/H0 u/X1 w/X3
V/H2 N/H0 v/X2 u/X1
W/H3 N/H0 w/X3 v/X2
Yz11 U/H1 V/H2 u/X1 n/X0
V/H2 W/H3 v/X2 n/X0
W/H3 U/H1 w/X3 n/X0
IEC 60076
vector
group
Winding Connection to CPC 100 TRRatio
settings
HV/H LV/X 2kV output V1 AC input
red black red black Vprim Vsec
U
V
W
w
u
v
U
V
W
w
u
v
U
V
W
w
u
v
U
V
W
u
v
w
U
V
W
wu
v
U
V
W
wu
v
U
V
W
w
v
u
U
V
W
v
u
w
U
V
W
v
u
w
