Omicron CPC 100 Reference Manual

CPC 100 V1.41
16 - 12
Table 7:
Technical data of
2kV AC output at a
voltage range of 500V
2kV AC output at a voltage range of 500V
Maximum current Peak current I
peak
< 12.0A
Effective current I
rms
< 5.0A
Output power at: typical apparent
power S
max
typical time t
max
frequency
500V / 5A
500V / 4A
500V / 2A
2500VA
2000VA
1000VA
60s
130s
> 2hrs
50…200Hz
50...200Hz
50...400Hz
Measurement
Voltage
Voltage and current
Range: 0 ... 500V AC
Accuracy: typ. error <± 0.05%(rd) ± 0.05%(fs),
guaranteed <± 0.1% (rd) ± 0.1% (fs)
Possible crest factor: < 1.5
Phase tolerance
at full scale:
typ. error < ± 0.2°,
guaranteed < ± 0.4°
