Omicron CPC 100 Reference Manual

CPC 100 V1.41
2 - 16
Context-dependent menu keys
Soft-touch keys that directly invoke specific commands associated with the
currently selected control of the test card and view.
Since their actual functions depend on the selected view, test mode, test card
and selected UI element, the menu keys do not hold any specific text. The
individual key function is displayed on the monitor with a labelled button symbol
right next to the menu key.
I/O (test start/stop)
If the test parameters are set in the software’s Test Card View, the Emergency
Stop button is released and the safety key lock is set to the "enable" position,
pressing this push-button enables CPC 100 outputs and starts a test.
Pressing this push-button a second time stops the test.
Tab selector
If a test procedure comprises more than one test card, use these keys to change
between the single test cards.
Note: Stopping a test does not shut off the CPC 100 outputs
instantaneously. First, the currently running test sequence finishes,
then the test execution is stopped.
Most test cards finish the running test sequence with a predefined
ramp function.
Therefore
, in a hazardous situation never press "Stop Test". Instead,
use Emergency Stop.
