4-14
Maintenance Ethernet Port
Use the maintenance Ethernet port to connect a PC directly to the AMR when using software for con-
figuration or troubleshooting. This port should only be used as a single connection point. Do not con-
nect the maintenance port directly to your LAN.
This port is located in the User Connections area on the Connector Panel.
This port automatically assigns an IP address to the connecting PC.
Access to the SetNetGo web interface is always enabled on this port and does not require a password
or software license.
Additional Information
Refer to 3-4 Network Connections on page 3-16 for more information.
4 Operation
4-31
AMR (Autonomous Mobile Robot) MD-series Platform User's Manual (I681)
4-14 Maintenance Ethernet Port
4
