FP2/FP2SHFP2/FP2SH Operation
6 − 30
6.8 FP2SH IC Memory Card Operation (for FP2−C2P/FP2−C3P)
Executing Programs
There are two ways to execute programs written on IC memory cards, described below.
1
Programs are automatically transferred when the power supply is turned on.
If the power supply is turned on when the DIP switches on the back of the CPU
are set so that both SW2 and SW4 are on, the “Autoexec.spg” file stored in the IC
memory card is sent to the internal RAM. When the mode is switched to RUN,
operation begins in accordance with the contents of that file.
Internal RAM
Program Data
Comment
Internal FROM
Data
Program
Autoexec.spg
IC memory card
FP2SH (FP2-C2P, FP2-C3P)
2
Sending programs from the “ROM & RAM service...” menu
If the power supply is turned on when the DIP switches on the back of the CPU
are set so that SW2 is off and SW4 is on, executing the “ROM → RAM” operation
causes the “Autoexec.spg” file stored in the IC memory card to be sent to the in-
ternal RAM. When the mode is switched to RUN, operation begins in accordance
with the contents of that file.
Before the “ROM → RAM” menu is executed, any contents loaded with the tool become
the contents of the internal RAM.
