11-5
FP2 (32K)
Users memory capacity : 32K words
Setting range of A : 2K to 32K words (default value: 12k)
Setting range of B : 0 to 30K words (default value: 0)
Setting range of C : 0 to 30K words (default value: 0)
Allocate so that A + B + C ≦ 32.
Setting example: The values of D when B = C = 0.
A
Area for sequence program
(1024 x A-512)
Area for file registers (D)
2
1,535 steps 30,717 words
4
3,583 steps 28,669 words
6
5,631 steps 26,621 words
8
7,679 steps 24,573 words
10
9,727 steps 22,525 words
12
11,775 steps (default value)
20,477 words (default value)
14
13,823 steps 18,429 words
16
15,871 steps 16,381 words
18
17,919 steps 14,333 words
20
19,967 steps 12,285 words
22
22,015 steps 10,237 words
24
24,063 steps 8,189 words
26
26,111 steps 6,141 words
28
28,159 steps 4,093 words
30
30,207 steps 2,045 words
32
32,255 steps 0 word
Setting example for each area
When not using the machine language program area
Refer to the tables for the different types given above.
When using the machine language program area
A
Area for machine language program
B
Area for machine language program
2
4,096 words
18
36,864 words
4
8,192 words
20
40,960 words
6
12,288 words
22
45,056 words
8
16,384 words
24
49,152 words
10
20,480 words
26
53,248 words
12
24,576 words
28
57,344 words
14
28,672 words
30
61,440 words
16
32,768 words
For example, for the FP2 (16K-step type), when the area for the sequence program (A) is set to 10K
words and the area for configuration (C) is set to 0K words, the area for the machine language program
can be set up to 6K words.
