11-33
FP2/FP2SH/FP10SH/FP3 (A: Available, N/A: Not available)
Address
Name Descriptions
Read-
ing
Writ-
ing
FP3
FP2/
FP2SH
FP10SH
DT9028
(*Note)
DT90028
Sample trace
interval
The value registered using programming
tool software is stored.
- K0: sampling triggered by F155
(SMPL)/P155 (PSMPL) instruction
- K1 to K3000 (x 10ms): 10ms to 30s
A N/A
DT9029
(*Note)
DT90029 Break address
The address (K constant) of a break in a
test run is stored.
DT9030
(*Note)
DT90030 Message 0
The contents of the specified message
are stored in these special data registers
when F149 (MSG)/P149 (PMSG)
instruction is executed.
DT9031
(*Note)
DT90031 Message 1
DT9032
(*Note)
DT90032 Message 2
DT9033
(*Note)
DT90033 Message 3
DT9034
(*Note)
DT90034 Message 4
DT9035
(*Note)
DT90035 Message 5
DT9036 DT90036
F152 (RMRD)/
P152 (PRMRD)
and
F153 (RMWT)/
P153 (PRMWT)
instructions end
code
The error code is stored here if F152
(RMRD)/P152 (PRMRD) or F153
(RMWT)/P153 (PRMWT) instruction was
executed abnormally.
When the instruction was successfully
executed, “0” is stored.
A N/A
Abnormal unit
display
If an abnormal unit is installed to the
backplane, the slot number of that unit
will be stored. Monitor using decimal
display.
DT9037 DT90037
Work 1 for
F96 (SRC)/
P96 (PSRC)
instructions
The number of data that match the
searched data is stored here when F96
(SRC)/P96 (PSRC) instruction is
executed.
A A
DT9038 DT90038
Work 2 for
F96 (SRC)/
P96 (PSRC)
instructions
The position of the first matching data,
counting from the starting 16-bit area, is
stored here when an F96 (SRC)/P96
(PSRC) instruction is executed.
DT9039 DT90039
F145 (SEND)/
P145 (PSEND)
and
F146 (RECV)/
P146 (PRECV)
instructions end
code
The error code is stored here if F145
(SEND)/P145 (PSEND) or F146 (RECV)/
P146 (PRECV) instruction was executed
abnormally.
When the instruction was successfully
executed, “0” is stored.
A N/A
Note) Used by the system.
