Panasonic fp2/fp2sh - Page 310

11-42
FP2/FP2SH/FP10SH/FP3 (A: Available, N/A: Not available)
Address
Name Descriptions
Read-
ing
Writ-
ing
FP3
FP2/
FP2SH
FP10SH
DT9148
(*Note1)
DT90148
MEWNET-
W/-P
PC(PLC)
link status
[PC(PLC)
link 1
(W/P)]
(*Note2, 3)
The number of times the receiving operation
is performed (counted using ring counter)
N/A N/A
DT9149
(*Note1)
DT90149
The current interval between two receiving
operations: value in the register x 2.5 ms
DT9150
(*Note1)
DT90150
The minimum interval between two receiving
operations: value in the register x 2.5 ms
DT9151
(*Note1)
DT90151
The maximum interval between two receiving
operations: value in the register x 2.5 ms
DT9152
(*Note1)
DT90152
The number of times the sending operation is
performed (counted using ring counter)
DT9153
(*Note1)
DT90153
The current interval between two sending
operations: value in the register x 2.5 ms
DT9154
(*Note1)
DT90154
The minimum interval between two sending
operations: value in the register x 2.5 ms
DT9155
(*Note1)
DT90155
The maximum interval between two sending
operations: value in the register x 2.5 ms
DT9156
(*Note1)
DT90156
MEWNET-
W/-P
PC(PLC)
link status
[PC(PLC)
link 0
(W/P)]
(*Note2, 3)
Area used for measurement of receiving
interval.
DT9157
(*Note1)
DT90157
Area used for measurement of sending
interval.
DT9158
(*Note1)
DT90158
MEWNET-
W/-P
PC(PLC)
link status
[PC(PLC)
link 1
(W/P)]
(*Note2, 3)
Area used for measurement of receiving
interval.
DT9159
(*Note1)
DT90159
Area used for measurement of sending
interval.
Note1) Used by the system.
Note2) When the system register 46 = K0, First: PC(PLC) link 0, second: PC(PLC) link 1
When the system register 46 = K1, First: PC(PLC) link 1, second: PC(PLC) link 0
Note3) For MEWNET-W system, available PLC type: FP2/FP2SH/FP3/FP10SH
For MEWNET-P system, available PLC type: FP3/FP10SH
