Panasonic fp2/fp2sh User Manual

FP2/FP2SHOverview
1 − 16
1.3 Expansion Function
Table of specifications
Item
Description
1:1 communication 1:N communication
Communication
method
Half
duplex
Half
duplex
C
ommun
i
ca
ti
on me
th
o
d
H
a
lf
d
up
l
ex
H
a
lf
d
up
l
ex
Synchronization method Start−stop synchronous system
Communication path RS232C cable Two-core cable
(VCTF 0.75mm
2
× 2C)
Transmission distance Max. 15m/49.2ft. Max. 1200m/3,937ft.
Transmission speed
(Baud rate)
1200bps/2400bps/4800bps/9600bps/
19200bps/38400bps/57600bps/115.2Kbps
9600bps/19200bps
Transmission code ASCII
Transmission format Stop bit: 1 bit/2 bits
Parity check: none/even/odd
Character bits: 7 bits/8 bits
Necessary devices in configuration
1:1 communication 1:N communication
FP2/FP2SH
Commercially available computer
Commercially available RS232C cable
(AFB85813/AFB85853 or equivalent)
FP2/FP2SH
Commercially available computer
Commercially available RS232C cable
(AFB85813/AFB85853 or equivalent)
C-NET adapter (AFP8536/AFP8532) × 1 piece
C-NET adapter S2 type (AFP15402) × number of PLC
Two-core cable (VCTF 0.75mm
2
)
