Panasonic fp2/fp2sh User Manual

11-88
Error
code
Name
Opera
-tion
status
Description and steps to take
FP-e FP0 FP0R FP
Σ
FP-X FP2 FP2SH FP10SH
E38
MEWNET-F
slave I/O
terminal
mapping
error
Stops
I/O mapping for remote I/O terminal
boards, remote I/O terminal units and I/O link
is not correct.
⇒Re-configure the I/O map for slave stations
according to the I/O points of the slave
stations.
A A A
E39
IC card
read error
Stops
When reading in the program from the IC
memory card(due to automatic reading
because of the dip switch setting or program
switching due to F14(PGRD) instruction):
- IC memory card is not installed.
- There is no program file or it is damaged.
- Writing is disabled.
- There is an abnormality in the
AUTOEXEC.SPG file.
- Program size stored on the card is larger
than the capacity of the CPU.
⇒Install an IC memory card that has the
program properly recorded and execute the
read once again.
A A
E40 I/O error
Sele-
ctable
Abnormal I/O unit.
FPΣ, FP-X:
Check the contents of special data register
DT90002 and abnormal FPΣ expansion unit
(application cassette for FP-X). Then check
the unit.
FP2 and FP2SH:
Check the contents of special data registers
DT90002,DT90003 and abnormal I/O unit.
Then check the unit.
Selection of operation status using system
register21:
-to continue operation, set 1
-to stop operation, set 0
Verification is possible in FPWIN GR/Pro at
“I/O error” in the status display function.
A A A A A
MEWNET-TR communication error
FP3 and FP10SH:
Check the contents of special data
registers(FP3:DT9002,DT9003,FP10SH:DT9
0002,DT90003) and the erroneous master
unit and abnormal I/O unit. Then check the
unit.
Selection of operation status using system
register21:
-to continue operation, set 1
-to stop operation, set 0
Verification is possible in FPWIN GR/Pro at
“I/O error” in the status display function.
A: Available
