FP2/FP2SHParts and Functions
2 − 14
2.2 FP2 CPU
Internal Circuit Diagram
24V DC
Input
COM
Input indicator LED
Internal circuit
5.6kΩ
560Ω
Pin Layout
24V DC 24V DC
The COM pins of each connector are connected internally.
