2.7 Power Supply Units
Specifications
Item Description
Part number FP2−PSA1 FP2−PSA2 FP2−PSA3 FP2−PSD2
Size of unit 1−module 2−module
Input Rated voltage 100 to 120V AC 200 to 240V AC 100 to 240V AC 24V DC
Current consumption 0.4A or less
(at 100V AC)
0.2A or less
(at 200V AC)
0.7A or less
(at 100V AC)
0.4A or less
(at 200V AC)
2.5A or less
Surge current 40A or less 30A or less
(at 25°C/77°F)
10A or less
Rated frequency 50Hz/60Hz —
Operating voltage
range
85 to 132V AC 170 to 264V AC 85 to 264V AC 20.4 to 31.2V DC
(*1)
Output Output capacity at 5V Max. 2.5A Max. 5A Max. 5A
Alarm contact capacity 30V DC 1A
Alarm contact operation When the ALARM LED of CPU is lit
Alarm contact type 1c contact
Leakage current Between input and ground terminals, 0.75mA or less
Breakdown voltage 1500V AC for 1 minutes
(between input and ground terminals)
500V AC for 1
minutes (between
input and ground
terminals)
Insulation resistance 100MΩ 500V DC (between input and ground terminals)
Guaranteed lifetime 20000 hours at 55°C/131°F
Overcurrent protection function Built-in overcurrent protection
Fuse Built-in
Terminal screw M3
*1 The allowable variation in voltage after startup is 15.6V to 31.2V.
