FP2/FP2SHParts and Functions
2 − 34
2.9 Input Units Specifications
Pin Layout
12 to 24V DC
12 to 24V DC
Input X0 to XF
For more information regarding the applicable pressure connection (crimp) terminals
and wiring, refer to section 4.5.1.
