Web-based management WBM
108580_en_02 PHOENIX CONTACT 201 / 272
Logging in as user If WBM user authentication is activated, log in using your user details.
• Enter your user name in the “Username” input field.
• Enter your password in the “Password” input field.
• To open WBM, click on the “Login” button.
The WBM start page opens (see Section 9.6).
9.6 WBM start page – Areas and functions
Figure 9-5 WBM start page
WBM is organized into the following areas:
– Information: general device information
– Diagnostics: PROFINET
– Configuration: update of the non-safety-related device firmware
– Security: user authentication, certificate authentication and firewall
– Administration:
Please note:
After changing the access data for the administrator, it is no longer possible to login with
the user name “admin” and the administrator password printed on the controller.
