Web-based management WBM
108580_en_02 PHOENIX CONTACT 215 / 272
9.7 Firmware update via WBM
This section describes the procedure for updating the non-safety-related firmware of the
RFC 4072S via Web-based management (WBM).
• Download the *.zip firmware file at phoenixcontact.net/product/1051328
.
• Unzip the *.zip firmware file.
• Run the *.exe setup file.
• Follow the instructions of the installation wizard.
During installation, the update file (*.raucb) and files containing device-specific information
(such as change notes and Phoenix Contact software license terms) are copied to the
selected destination directory.
• Open WBM of the RFC 4072S by entering the IP address in the web browser.
• Log onto the RFC with your user name and password. The user name and password
are printed on the label attached to the side of the device (see Figure 2-32 on page 67).
• First, select “General Data” in the “Information” area (A in Figure 9-20). Take down the
firmware version specified (B in Figure 9-20). You will need it for the final check after the
update.
Figure 9-20 WBM: Information – General Data (firmware version)
• In the “Administration” area, click on “Firmware Update” (A in Figure 9-21).
