RFC 4072S
228 / 272
PHOENIX CONTACT 108580_en_02
Characteristic data of the safety-related PROFINET controller iSPNS 3000
Programming system PLCnext Engineer, IEC 61131
CPU1 (Central Processing Unit 1)
CPU2 (Central Processing Unit 2)
ARM
R
Cortex
R
-A9, 800 MHz
ARM
R
Cortex
™
-A8, 600 MHz
Shortest cycle time T
ZSPNSmin
5ms
Program memory 1Mbyte
Data storage 128 kbytes
PROFIsafe profile V2.6.1 (also includes support for V2.4)
Number of PROFIsafe F-Devices 300
Sum of all bytes of the safety-related input messages 8192 bytes, maximum
Sum of all bytes of the safety-related output messages 8192 bytes, maximum
Exchange area for data direction “I” 3072 bytes
Exchange area for data direction “Q” 3072 bytes
Buffer times of the integrated realtime clock (RTC)
Typical buffer time 15 days
Guaranteed buffer time 10 days
Conformance with EMC directive 2014/30/EU
Immunity test in accordance with EN 61000-6-2
Electrostatic discharge (ESD) EN 61000-4-2/
IEC 61000-4-2
Criterion B
6 kV contact discharge
8 kV air discharge
Electromagnetic fields EN 61000-4-3
IEC 61000-4-3
Criterion A
Field strength: 10 V/m
Fast transients (burst) EN 61000-4-4/
IEC 61000-4-4
Criterion B
Supply lines: 2 kV
Signal/data lines: 2 kV
Transient overvoltages (surge) EN 61000-4-5
IEC 61000-4-5
Criterion B
Signal/data lines: 1 kV
Supply lines: 0.5 kV
Conducted disturbance variables EN 61000-4-6
IEC 61000-4-6
Criterion A
Test voltage 10 V
Noise emission test according to EN 61000-6-4 Class A
NOTE: Radio interference
This is a Class A item of equipment. When using the equipment in residential areas, it may cause radio inter-
ference. In this case, the operator may be required to implement appropriate measures and to pay the resulting
costs.
