LIFEPAK 20/20e Defibrillator/Monitor Troubleshooting
Troubleshooting Chart (continued)
Area Observed Symptom Suggested Corrective Action
ECG lead characteristics
(continued)
No amplitude ECG Check or replace the ECG cable.
Replace the A02 Patient Parameter PCB.
ECG gain out of tolerance Check simulator output.
Check or replace the ECG cable.
Check or replace the A02 Patient Parameter PCB.
Therapy - Paddle ECG
lead characteristics
ECG gain out of tolerance Check simulator output.
Check or replace the therapy cable.
Check or replace the A01 System PCB.
ECG analog out (missing or
out of tolerance)
Check simulator output.
Check ECG on display.
Check W11 ECG out connector.
Remote sync No remote sync Turn on remote sync function.
Check ECG Out/Sync In connector. If bad, replace the
A03 Power module.
Check or replace the W09 Power Cable.
Check or replace the A01 System PCB.
Check or replace the A03 Power module.
(Continued on next page)
6-10
