LIFEPAK 20/20e Defibrillator/Monitor Replacement Procedures
Bottom Case (continued)
A13 Energy Capacitor
Removal
Note: Remove the following assemblies before beginning this disassembly:
– A07 Battery
– Top case
– Front case
To remove the A13 Energy Capacitor:
1. If the boardstack assembly was not removed, remove and discard the screw
and ground cable (221).
2. Disconnect the W10 Power/Therapy Cable from the A04 Therapy PCB at
J17.
3. Pull the boardstack assembly away from the printer shroud (89) and the
power module.
4. Disconnect the W07/A13 Capacitor Discharge Cable from the A04 Therapy
PCB at J2.
WARNING
SHOCK HAZARD. Carefully follow disassembly instructions to avoid a shock or
causing damage to wires during disassembly.
(Continued on next page)
