LIFEPAK 20/20e Defibrillator/Monitor Device Description
System Context Diagrams
Front of Device
The system context diagrams illustrate how the device connects with external
equipment, including accessories, batteries, and power devices.
(Continued on next page)
QUIK-COMBO
therapy cable
(QUIK-COMBO
electrodes)
Standard paddles
A
P
E
X
S
T
E
R
N
U
M
SpO2 cable
5-lead ECG
cable
ECG electrodes pack
3-lead ECG
cable
(3) rolls 50 mm
printer paper
3-17
