LIFEPAK 20/20e Defibrillator/Monitor Replacement Procedures
Front Case (continued)
Parts List (continued)
Parts A05–W15 Parts 161–284 Front Case View Rear View Main Assemblies
Item Quantity MIN CAT. Part Description Note
W02 1 3319086-001 21300-008133 Speaker Assembly RoHS
W02 1 3201593-004 21300-004247 Speaker Assembly Non-RoHS
W04 1 3201145-000 21300-004264 Speed Dial Assembly
W15 1 3300152-000 21300-007774 Active Color Display Cable
W17 1 3200996-002 21300-004237 Active Backlight Inverter Cable
W18 1 3201000-004 21330-008056 UI to Stack Flex Assembly
9 1 3200624 see note Front case Part of kit MIN 3202718-001
12 1 3206034-XXX see note Label set (6 labels) Refer to Labels Assembly
17 1 3200633-000 21300-004620 Speed Dial knob
19 1 3200638-001 21300-004837 Cover plate, door Part of kit MIN 3202718-001
23 1 3201499-009 21501-000767 Manual latch label Select other language
9-28
